Furuno GPS Antenna GPA-017 with 10m Cable - TNC Plug

Furuno

$269.00

Quantity
  • Antenna for GPS signal reception (L1 band). For timing applications and with high noise resistance, Multi-GNSS antenna AU-217 offers the best solution.
  • The antenna consists of the antenna for receiving GPS signal, the filter for band limitation and the preamplifier for signal amplification.

  • Power supply for preamplifier operation is supplied by overlapping the signal line.

  • Wide range of power supply from 4VDC to 13VDC.
  • Easy installation by using optional antenna fixing bracket.

Input Frequency - 1575.42MHz ±1.023MHz
Polarization -  R. H. C. P. (Right Hand Circular Polarization)
Antenna Gain
<= 2.0dBi (at 90° elev. angle)
<= -4.0dBi (at 10° elev. angle)
Output Impedance - 50 ©
Pre. Amp Gain - 27.5 ±5.5dBPre.
Amp Noise Figure - <= 1.6dBVSWR<= 2.0
Supply Voltage - 4 to 5.5VDC
Power Consumption - <= 25mA
Operating Temperature - -25°C to +70°C
Storage Temperature - -35°C to +75°C
Operating Relative Humidity - <=95%RH
Connector Type -  TNC-J
Note - Standard type

SKU: GPA017 10M TAG: GPS Antennas
