Garmin - AIS 800 Blackbox Transceiver

Garmin

$1,943.00

Quantity

Increase your situational awareness and confidence on the water with the Garmin AIS 800 transceiver. It has 5 watts of transmit power and provides faster position reporting than ever before. It transmits your vessel information to other AIS receivers in your area while it receives their AIS target data. Garmin AIS 800 has an internal VHF antenna splitter, which allows the VHF and AIS to share a single antenna. It includes a built-in GPS (Requires GA38 external antenna) and integrates seamlessly into the Garmin onboard system. The transceiver features NMEA 2000/0183 connectivity for easy integration with compatible chartplotters and multifunction displays. And it's all packed into an easy-to-install black box unit with a small footprint.

Features

  • Dimensions: 17.5 x 14.2 x 5.5 cm
  • Weight: 0.9 lbs (414 g)
  • Operating Temperature Range: 5°F to 131°F (-15°C to 55°C)
  • Waterproof Rating: IPX7
  • Compass safe distance: 15.8" (40 cm)
  • Operating Voltage: 9.6 - 31.2 Vdc
  • Current Drain: 12Vdc: < 400 mA; 24Vdc: <250 mA
  • Antenna Connector: S0-239 (50©)
  • GPS refresh rate: 1 Hz
  • Max Antenna Gain: 9 dB
  • Transmitter Power: 5 W
  • NMEA 2000 LEN: 2
  • NMEA 0183: Yes

In the box

  • AIS 800
  • NMEA 2000® T-connector
  • NMEA 2000 drop cable (2 meters)
  • VHF antenna extension (1.2 meters)
  • USB adapter cable
  • Power cable
  • Mounting hardware
  • Documentation
SKU: AIS800 TAG: AIS
